Brass Hydraulic Connector Investment Casting

Product Overview

Brass Hydraulic Connector is a precision investment casting component manufactured by Wuxi Huayong Metal Technology Co., Ltd. Our investment casting process ensures exceptional dimensional accuracy, superior surface finish, and excellent mechanical properties. Unlike sand casting, investment casting produces near-net-shape components with minimal machining requirements, reducing overall cost and lead time.

All our brass hydraulic connector castings are custom manufactured based on customer drawings or samples. We work closely with our clients' engineering teams to optimize designs for castability, ensuring high-quality, defect-free castings at competitive prices. Every component undergoes rigorous quality control including chemical analysis, mechanical testing, and non-destructive testing.

Material Options

We offer a wide range of materials for brass hydraulic connector castings, including stainless steel, carbon steel, alloy steel, copper alloys, and heat-resistant alloys. All materials are sourced from certified suppliers and verified with spectrometer analysis.

Material Family	Common Grades	Key Properties	Typical Applications
Stainless Steel	CF8M, CF8, CF3M, CF3, 316L, 304L	Excellent corrosion resistance, good mechanical properties	Chemical, food, marine, water treatment
Carbon Steel	WCB, WCC, LCC, LC2	Good strength, weldability, cost-effective	Oil & gas, power, general industrial
Alloy Steel	WC6, WC9, C5, C12A, 42CrMo	High temperature strength, wear resistance	Power generation, high-temp service, automotive
Duplex Steel	CD4MCu, CD3MN, 2205	High strength, excellent pitting resistance	Oil & gas, desalination, chemical
Copper Alloy	C95400, C93200, C83600, Tin Bronze	Excellent wear resistance, corrosion resistance	Bearings, gears, marine, decorative
Heat Resistant	HK30, HU31, 310S, 309S	High temperature oxidation resistance	Furnace parts, heat treatment, power

Manufacturing Process

1. Pattern Making

We produce high-precision wax patterns using injection molding. The wax patterns are exact replicas of the final brass hydraulic connector, including all internal passages and external features.

2. Shell Building

The pattern tree is repeatedly dipped into ceramic slurry and coated with refractory sand. This process is repeated 6-8 times to build a strong, heat-resistant ceramic shell.

3. Dewaxing & Preheating

The ceramic shell is placed in an autoclave where steam melts the wax, which drains out. The empty shell is then preheated to 1000-1100°C to remove residual moisture.

4. Melting & Pouring

Metal is melted in induction furnaces under carefully controlled conditions. The molten metal is poured into the preheated ceramic shells.

5. Shell Removal & Cutting

After solidification and cooling, the ceramic shell is removed by mechanical vibration and blasting. The individual components are then cut from the sprue.

6. Heat Treatment

All castings undergo proper heat treatment to achieve optimal mechanical properties and material structure.

7. CNC Machining

The cast brass hydraulic connector are precision machined on CNC lathes and machining centers. We maintain tight tolerances on critical dimensions.

8. Surface Treatment & Testing

Finished components undergo surface treatment and comprehensive quality testing including dimensional inspection, chemical analysis, and non-destructive testing.

Quality Control & Testing

We maintain rigorous quality control at every stage of production to ensure that every Brass Hydraulic Connector meets or exceeds customer specifications:

• Chemical Analysis: Spectrometer analysis of every heat, with full material test certificates (EN 10204 3.1)
• Mechanical Testing: Tensile strength, yield strength, elongation, and hardness testing per ASTM A370
• Dimensional Inspection: CMM (Coordinate Measuring Machine) inspection of critical dimensions
• Non-Destructive Testing (NDT): Radiographic testing (X-ray), liquid penetrant testing, ultrasonic testing as required
• Microstructure Examination: Metallographic analysis to verify grain structure and detect defects
• Pressure Testing: Hydrostatic pressure testing for pressure-containing components

Applications

Our brass hydraulic connector castings are used in a wide range of industries and applications:

• Oil & Gas: Upstream, midstream, and downstream processing, refineries, pipelines
• Chemical Processing: Acid handling, chemical reactors, transfer lines
• Power Generation: Thermal power, nuclear power, renewable energy
• Water Treatment: Desalination, wastewater treatment, water distribution
• Food & Beverage: Processing, filling, CIP systems, sanitary applications
• Pharmaceutical: Drug manufacturing, sterile processing, biotech
• Marine: Shipbuilding, offshore platforms, desalination
• Automotive: Engine components, transmission parts, exhaust systems
• Aerospace: Aircraft components, turbine parts, structural components
• Pulp & Paper: Bleaching, chemical recovery, stock preparation

Why Choose Huayong for Your Brass Hydraulic Connector Castings?

• Complete In-House Capability: From wax pattern to final CNC machining — all under one roof for better quality control
• Material Expertise: Experienced in stainless steel, carbon steel, alloy steel, copper alloys, and specialty alloys
• ISO 9001 Certified: Rigorous quality management system with full traceability
• Custom Manufacturing: All parts made to your exact drawings and specifications
• Competitive Pricing: Factory-direct pricing with no middleman markup
• Fast Response: Quotations within 48 hours, technical support 24/7
• Global Export Experience: Serving clients in Europe, North America, Middle East, and Southeast Asia
• Flexible MOQ: From prototype quantities to mass production

Engineering Design Tips for Valve & Fitting Castings

1. Wall Thickness & Pressure Integrity

Design valve bodies with wall thickness appropriate for the pressure rating. Follow ASME B16.34 or equivalent standards for pressure-temperature ratings. Maintain uniform thickness to minimize shrinkage, with generous fillets at section transitions.

2. Port & Seat Pocket Design

Ensure adequate material around seat pockets and threaded ports for machining allowance. Recommended machining allowance: 2-3mm per surface for CNC operations. Seat sealing surfaces require precise flatness and surface finish.

3. Flange Design

Flange faces should be designed with sufficient thickness to allow for facing operations while maintaining pressure rating integrity. Consider post-cast heat treatment before machining to relieve residual stresses.

4. Draft & Core Design

Design with minimum 1° draft angle for external surfaces and 1.5° for internal surfaces. Complex internal valve passages may require soluble cores or multi-piece wax assembly.

5. Material Selection for Corrosive Service

For corrosive environments, select CF8M (316), CF3M (316L), CD4MCu (Duplex 2205), Alloy 20, or Hastelloy C276. For high-temperature service, consider HK30 or HH30 heat-resistant alloys.

Frequently Asked Questions

Q: What valve components can you cast?

A: We cast valve bodies, bonnets, valve discs, plugs, seats, glands, yokes, brackets, and custom valve components for ball, gate, globe, check, butterfly, and control valves.

Q: What pressure ratings can you achieve?

A: Our cast valve bodies can be rated up to Class 2500 / PN400 depending on size, material, and design. All pressure-containing parts undergo hydrostatic testing.

Q: Can you cast valves with complex internal passages?

A: Yes, investment casting excels at complex internal geometries. We can produce multi-port valves, control valve bodies, and valves with intricate internal flow paths.

Q: Do you provide fire-safe or cryogenic certified castings?

A: Yes, we can produce castings meeting API 607 fire-safe requirements and cryogenic service standards. Material certification and traceability are fully documented.
